Description
-
1 Reed Switch (side)
-
One-Push-To-Learn Button
-
Pyronix High Security Wireless Protocol Encryption
-
868MHz Transceiver FM technology
-
Complies with EN50131-1
-
Available in white, brown or anthracite grey
Security and safety sensors technical characteristics
Magnetic contact |
Yes |
Tamper protection |
Front and rear |
LED sensor test |
Signal, Alarm |
Magnet included |
Yes |
Enforcer two-way wireless technology
Signal Strength Indicators (SSI) |
Yes |
Instant two way device control (ITDC) |
Yes |
Pyronix high security two way wireless data encryption protocol (TDE) |
Yes |
Pyronix intelligent jamming detection |
Yes |
Programmable wireless supervision time |
Yes |
868MHz transceiver FM technology |
Yes |
One push to learn |
Yes |
Tranmission method |
Fully encrypted rolling |
Transmission range |
300m in open space |
Environmental and operating features
Storage temperature |
-20C to 50C. |
Certified operating temperature |
-10C to 40C |
Nominal operating temperature |
-10C to 50C |
Physical dimensions (H x W x D) |
27 x 104 x 25mm | Magnet: 14 x 49 x 16mm |
Electrical & battery
Battery type |
1 x CR123A 3V lithium battery |
Battery life |
up to 2 years |
Threshold |
2.5V +/- 5% at 25C |
Certifications and warranty
Security Grade |
Grade 2 |
Environmental class |
II |
EN Certificate |
EN50131-2-6:2008 | EN50131-5-3:2005+A1:2008 | PD6662:2017 |
Certification type |
IMQ |
Certificate number |
CA12.01482 |
Electrical conformity |
CE |
Warranty |
2 years |
