Description
PRODUCT FEATURES
-
10m pet tolerant detection up to 20kg
-
Secure two-way wireless
-
Dual element pyro-electric sensor
-
Blue Wave Technology
-
Digital temperature compensation
-
Sealed optics
-
Signal Strength Indicator (SSI)
-
One Push to Learn Button
-
868MHz transceiver FM technology
-
Pyronix High Security Wireless Protocol Encryption
-
Complies with EN50131-1
Detectors technical characteristics
Blue Wave technology |
Yes |
Automatic sensitivity |
Yes |
Digital temperature compensation |
Yes |
Tamper protection |
Front and rear |
Signal Strength Indicators (SSI) |
Yes |
Enforcer two-way wireless technology
Signal Strength Indicators (SSI) |
Yes |
Instant two way device control (ITDC) |
Yes |
Pyronix high security two way wireless data encryption protocol (TDE) |
Yes |
Pyronix intelligent jamming detection |
Yes |
Programmable wireless supervision time |
Yes |
868MHz transceiver FM technology |
Yes |
One push to learn |
Yes |
Tranmission method |
Fully encrypted rolling code |
Transmission range |
300m in open space |
Detectors technical characteristics
Maximum range |
10m |
Animal immunity |
25kg |
Detection zones |
52 |
Detection planes |
5 |
Mounting
Optimum coverage height |
1.8 - 2.4m |
Certified mounting height |
1.8 - 2.4m |
Environmental and operating features
Storage temperature |
-20C to 50C |
Certified operating temperature |
-10C to 40C |
Nominal operating temperature |
-10C to 50C |
Physical dimensions (H x W x D) |
117 x 69 x 50mm |
Electrical & battery
Battery type |
1 x CR123A |
Battery life |
up to 2 years |
Battery voltage |
3.0V |
Low battery threshold |
2.5V +/- 5% at 25C |
Certifications and warranty
Security Grade |
Grade 2 |
Environmental class |
II |
EN Certificate |
EN50131-5-3: 2005 + A1: 2008, EN50130-4: 1995 + A1: 1998 + A2: 2003, EN61000-6-3: 2007 |
Certification type |
IMQ |
Certificate number |
CA12.01426 |
Electrical conformity |
CE |
Warranty |
2 years |
